This product is a full 4K 4 x 4 HDMI seamless matrix switcher. It features compact enclosure, instant switching and free scaling up to 4K@60Hz SDR and HDR on all outputs. It also supports two additional working modes including multiview and videowall.
In matrix switcher mode, it allows four sources to be switched to four HDMI outputs seamlessly. In multiview mode, it features 5 layout modes, including Original, Dual view, PIP, Master and Quad. In videowall mode, the matrix supports 2x2 videowall layout, which can select any input for videowall outputs, configure bezel correction and set image rotation. Besides flexible video features, it also provides both analog and digital S/PDIF audio de-embedding for outputs 1&2. The product can be easily managed and controlled, for example, through front panel buttons, IR, RS232, web UI and TCP protocols.

Features

• Seamless switching without seeing black screen between four HDMI inputs and outputs.
• Each HDMI input and output support video format up to 4K@60Hz SDR and HDR.
• HDCP 2.3 and backward compatible.
• EDID management including EDID presets, EDID copy and custom EDID.
• Advanced video processing capabilities:
  • Supports free scaling between 480p and 4K@60Hz.
  • Supports conversion between SDR and HDR formats.
  • Supports conversion on color space, chroma and color bits.
  • Supports instant switching between sources so black screen transition is avoided.
  • Supports rich scaler processing modes, including autoscaler, manual scaler and video bypass.
• Supports three video working modes:
• Supports matrix switcher mode, which can route any input to any output;
• Supports multiview mode, including Original mode, Dual view mode, PIP mode, Master mode, and Quad mode;
• Supports videowall mode (2x2 layout), and configuring its output distribution, bezel correction, input selection, and image 180° rotation (to facilitate 2x2 videowall setup using TV display) through API commands and web UI.
• Can be easily managed and controlled through front panel buttons, IR, RS232, web UI and TCP protocols.
• Supports firmware upgrade through web UI and Micro USB port.
