360° Varifocal 4 x 5MP IP Dome Camera |
 |
Advanced Analytics - Supports line cross, enter/leave area, face detection |
 |
NightColor - Provides extremely detailed color images even in low light |
 |
Low Light - 0.002 Lux |
Overview
The Illumivue IP20MVQL-NC/CAP 4 x 5MP LightHunter Multi-Sensor VF Network Dome Camera with Pendant Cap is a powerful multi-channel surveillance solution designed for security dealers and integrators who want to offer top-knotch security systems. With four independent sensors in a single IP device, this camera reduces installation time, infrastructure costs, and overall system complexity.
Each channel delivers 5MP resolution (2880×1620 @ 30fps) and can be independently adjusted for pan, tilt, and rotation, allowing flexible coverage in complex environments. The NightColor technology ensures superior low-light performance, while 130dB WDR provides clear imaging in high-contrast scenes.
Advanced analytics—including smart intrusion prevention with false alarm filtering, face capture, and people counting—enable high-value deployments across commercial, retail, and enterprise applications. Support for multiple intelligent functions per channel allows simultaneous analysis for enhanced operational insights.
With Ultra 265/H.265/H.264 compression, this camera optimizes bandwidth and storage efficiency. Built with IP67 protection, it is ideal for demanding indoor and outdoor installations requiring durability and long-term reliability.
Features
- 360° Multi-Sensor Camera
- 4 Channels in One IP
- 4 x 5MP Resolution (2880×1620 @ 30fps per Channel)
- Varifocal Lens 2.8-12mm (all 4 lens)
- Independent Lens Adjustment (Pan, Tilt, Rotation)
- LightHunter NightColor Low-Light Technology
- 130dB Wide Dynamic Range (WDR)
- Smart Intrusion Prevention with False Alarm Filtering
- Face Capture & People Counting Analytics
- Ultra 265 / H.265 / H.264 Compression
- IP67 Weatherproof Design
Support
Manuals & Technical Documents
Product Sheet
DownloadCompliance
FCC Compliance Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
National Defense Authorization Act (NDAA)
The National Defense Authorization Act (NDAA), particularly Section 889, has significant implications for the surveillance industry, especially concerning the procurement of video surveillance equipment. Section 889 prohibits U.S. federal agencies and their contractors from purchasing or using telecommunications and video surveillance equipment from certain manufacturers due to national security concerns.
As security integrators operating in the public sector and government markets, it’s critical to partner with brands that meet U.S. regulatory compliance. Illumivue is fully NDAA-approved, meaning our cameras, recorders, and associated components comply with the National Defense Authorization Act’s requirements that restrict use of certain foreign-made surveillance equipment. This gives you confidence when proposing Illumivue to municipalities, schools, and other agencies that must comply with these standards. Beyond compliance, Illumivue products deliver advanced capabilities—such as full-color night imaging (NightColor), dual-illumination modes (NightLight), intelligent analytics (line crossing, auto tracking, object counting), and plug-and-play setup—that make them a compelling solution both technically and contractually.
